Scan-gallery



Sample: Central part of the ant eye (family Formicidae). Eye consists of many smaller eyes with diameter 15 µm.
Image courtesy: Dr. Jan Soltys (Institute of Electrical Engineering, Slovak Academy of Sciences)
Scan size: 60x55 µm
Probe:
CSG10
Sample:  AFM-image of polyvinyl alcohol film containing tripsin. Crystalline part of polymer film.
Image courtesy: Ms. Alexandra A. Sertsova (Moscow State Textile University 'A.N. Kosygin')
Scan size: 12.5x12.5 µm
Probe:
CSG01
